NMA110B NMA111B-O 型圈式机械密封-宁波方力密封件有限公司


NMA110B NMA111B

产品简述

    ( 产品认证 )
  • 工作参数(Operating Conditions)

    温度(Temperature):-40℃~ +250℃
    压力(Pressure):≤ 2.5MPa
    线速度(Speed):≤ 15m/s

  • 适用介质(Applications)

    清水、污水、油及其它强腐蚀流体
    Clean water, sewage water, oil and other strong corrosive fluids

  • 材料(Materials)

    动环(Rotary Ring):Q1,Q2,V1
    静环(Seat Ring):Q1,Q2,B,A
    辅助密封(Secondary Seal):V,P,E,M1,M2,T
    弹簧及结构件(Spring and Metal Parts):F,G,M

  • 静环适合类型(Seat Types)

    标准(Standard):G90
    可替换(Alternative):G6,G4,G46
